NOVA INFINITY ACCESSORY BOWL JAW #3
Nova SKU 8303
The NOVA Infinity Quick Change delivers fast and positive jaw changes which is much faster and less hassle than the screw fastening method with the older NOVA chuck models and other chuck brands. The NOVA Infinity Jaw Key and Infinity Jaws Slides are a precision cast metal amalgam 3 times the tensile strength of machine grade steel. Jaw Key positively taper locks into Jaw slide with an embedded dovetail design. A stronger and more rigid bond than the original NOVA Screw on Jaws. The Infinity Jaws are cam locked inline with the forward rotation of the chuck. They are safe to use at higher speeds and larger turning work. The Infinity Jaws are larger, more robust and rigid than the older jaw designs, providing enhanced workholding and turning possibilities. The Infinity Jaws use the well proven NOVA Dovetail Profile, designed to grip the wood firmly for added safety.
The NOVA Infinity Bowl Jaws #3 are capable of holding:
Contracting Grip: Ranges from 46mm/1.811"- 53mm/2.087” (on the NOVA Precision Midi Chuck) through to 46mm/ 1.81"- 80mm/3.15" (on the NOVA Titan II Chuck) For more sizes see the NOVA product information sheet
Expansion Grip: Ranges from 68mm/2.68"- 75mm/2.95" (on the NOVA Precision Midi Chuck) through to 68mm/ 2.68"- 102mm/4.016" (on the NOVA Titan II Chuck) For more sizes see the NOVA product information sheet
Jaw Spigot Length: 12.5mm/0.492"
The standard equipment includes 4 x #2 Infinity Bowl Jaws Segments, 1 x Quick Start Instruction Manual. All backed by our comprehensive NOVA 2-Year Full Replacement Warranty. Call our customer service center toll free on 1-866-748-3025.
- Standard Infinity Chuck Jaw designed to hold medium bowls, plates & platters.
- External dovetail to grip internal bowl recess. Internal dovetail to grip bowl foot. Able to grip round dowels. Capacity overlaps #2 Bowl Jaws
- Stronger jaw design, over 15% thicker base, 130% wider jaw face than traditional Nova JS50N Jaws for max stability & rigidity
- 20% more external dovetail recess depth compared to traditional Nova JS50N Jaws means more useable grip available
- Larger grip capacity than traditional standard Nova JS50N Jaws
- Chuck, NOVA, Accessory, 4-Jaw Chuck
- 6-Year Full Replacement
